SMARTEYE Mark III Miniature High Performance Sensor

*Name

*Company

Street

City

State

Zip/Postal code

*Country

*Email

Telephone

High performance photoelectric sensor in a miniature size that you can use anywhere... for any task... including your toughest industrial sensing applications. Loaded with features and benefits including high-gain and high-speed of response (50 microseconds). High-gain enables the sensor to resolve the most difficult low contrast sensing tasks. High-speed response time provides resolution of the exact position of objects traveling at high speeds. It can either be side mounted or Din rail mounted with the universal DRB-1. Epoxy encapsulated, it is rugged and vibration proof.

CLS

Features
Specifications
Dimensions
Models & Ranges
Light Source
Optical Blocks
Applications
Downloads

OFFSET/EDR^® ADJUSTMENT
(Patent No. 5,621,205)
With the Offset/EDR^® adjustment feature, the SMARTEYE^® Mark III sensor can resolve very low contrast sensing tasks over a wider range of light intensities, including proper operation at high light levels. In addition, EDR^® improves background suppression.

EDR INDICATOR
As the OFFSET/EDR^® adjustment is rotated in the counterclockwise direction, the green EDR^® indicator LED will begin to turn on and glow dimly. As the counter clock wise rotation proceeds, the intensity of the EDR^® indicator will continue to increase. This indicator provides the installer an idea of just where in the overall dynamic operating range of the sensor the OFFSET/EDR<sup.® adjustment has been set.

DIN-RAIL MOUNTING
Install optional DRB1 universal mounting bracket to install on Din-Rail.

CONTRAST INDICATOR
The CONTRAST INDICATOR displays a scaled reading of the level of light received by the sensor’s photo detector. The more light received, the higher the reading. The less light received, the lower the reading.

HIGH-RESOLUTION & HIGH-SPEED
High resolution and speed combined. Can be used in virtually any sensing task without limits in sensing performance.

VERSATILITY
Change operating mode. Quick change” optical blocks allows one sensor to be used in proximity, convergent, retroreflective, polarized retroreflective, and fiberoptic applications.

CONNECTIONS
Built-in M12 connector for use with quick disconnect cable.

MARK III General Purpose Photoelectric Sensor Features

Features and Options:

Din-rail mountable
Small size
Response time (50 microseconds)
Enhanced Dynamic Range
Interchangeable optical blocks
Clutched offset adjustment
Operational from 12 to 30 VDC…(polarity protected)
Choice with infrared, red, white, or blue LED
10-LED CONTRAST INDICATOR
Waterproof housing
NPN and PNP output transistors
Short circuit protection
Light On/Dark on selector switch
Anti-pulsing protection on power up

Benefits:

Accurate and repeatable
Easy to setup
Easy to maintain
Lower maintenance costs
Lower inventory costs
Adaptable and flexible for many applications

SUPPLY VOLTAGE:
12 to 30 VDC
Polarity Protected

CURRENT REQUIREMENTS:
8 milliamps (exclusive of load)

OUTPUT TRANSISTORS:
(1) NPN sensor output transistor
(1) PNP sensor output transistor
Outputs sink or source up to 150 milliamps (current limit)
Momentary short circuit protected at power up.

RESPONSE TIME:
Light state response = 50 microseconds
Dark state response = 140 microseconds
Leading edge variation less than 20 microseconds

LED LIGHT SOURCE:
Options: Infrared= 880nm, Red= 660nm, Blue= 480nm,
White= Broadband spectrum. Pulse Modulated

RUGGED CONSTRUCTION:
Chemical resistant high impact polycarbonate housing
Waterproof, NEMA 4X, 6P, and IP67 enclosure rating
Conforms to heavy industry grade CE requirements

AMBIENT TEMPERATURE:
-40ºC to 70ºC (-40ºF to 158ºF)

DIMENSIONS:
Width: 2.35 in (59.69mm),
Height: 1.38 in (35.3mm),
Depth: .48 in (12.2mm)

MAXIMUM SENSING RANGE:
Retroreflective: up to 20 ft.
Proximity: up to 3 ft.
Fiberoptic Prozimity: up to 7 in.
w/o lens / 1 ft. w/lens
Fiberoptic Opposed Mode: up to 16 in.
w/o lens / 20+ft. w/lens

Features and Options:

Response time (50 microseconds)
Enhanced Dynamic Range
Interchangeable optical blocks
Clutched offset adjustment
Operational from 12 to 24 VDC…(polarity protected)
Choice with infrared, red, white, or blue LED
10-LED CONTRAST INDICATOR
Built-in connector
Waterproof housing
NPN and PNP output transistors
Short circuit protection
Light On/Dark on selector switch
Anti-pulsing protection on power up

Benefits:

Accurate and repeatable
Easy to setup
Easy to maintain
Lower maintenance costs
Lower inventory costs
Adaptable and flexible for many applications

MARK III Dimensions

Features and Options:

Response time (50 microseconds)
Enhanced Dynamic Range
Interchangeable optical blocks
Clutched offset adjustment
Operational from 12 to 24 VDC…(polarity protected)
Choice with infrared, red, white, or blue LED
10-LED CONTRAST INDICATOR
Built-in connector
Waterproof housing
NPN and PNP output transistors
Short circuit protection
Light On/Dark on selector switch
Anti-pulsing protection on power up

Benefits:

Accurate and repeatable
Easy to setup
Easy to maintain
Lower maintenance costs
Lower inventory costs
Adaptable and flexible for many applications

1. Select Sensor Model based on light source required

SE3I - Infrared
SE3R - Red
SE3B - Blue
SE3WL - White

2. Select connection required

Blank - Cable
C - Connector

3. Select Optical Block based on mode of sensing required:

F4 - Glass Fiberoptics
F5 - Plastic Fiberoptics
O4 - Proximity
O5 - Proximity
R4 - Retroreflective
R5 - Polarized Anti-Glare Retroreflective
V4 - Convergent 1" "V" Axis
V4A - Apertured
V6 - Convergent 1.5" "V" Axis
V8 - Convergent 0.5" "V" Axis

Sensing Range Guidelines

Convergent / Proximity / Retroreflective
Optical Blocks	IR	RED	BLUE	WHITE
V4, V4A	1in.	1in.	1in.	1in.
V6	1.5in.	1.5in.	1.5in.	1.5in.
V8	.5in.	.5in.	.5in.	.5in.
O4	1.5ft.	11in.	4in.	3in.
O5	4ft.	3ft.	1.5ft.	1ft.
R4	20ft. +	18ft. +	6ft.	5ft.
R5	N/A	7ft.	4ft.	3ft.
Note: Proximity tests utilized a 90% reflective with target. Retroreflective tests utilized a 3" diameter round reflector, Model AR3.
Glass Fiberoptics
Optical Blocks	IR	RED	BLUE	WHITE
Opposed Mode
F4	3ft.	1ft.	8in.	5in.
F4 w/lens	20ft. +	20ft. +	12ft.	9ft.
Proximity Mode
F4	7in.	5in.	1in.	1in.
F4 w/lens	1ft.	1ft.	N/A	6in.
Note: Proximity tests utilized a .125" diameter fiber bundle.
Plastic Fiberoptics
Optical Blocks	IR	RED	BLUE	WHITE
Opposed Mode
F5		9in.		2in.
F5 w/lens		6ft.		2ft.
F5 w/right angle lens		3ft.		1ft.
Proximity Mode
F5		7in.		5in.
F5 w/lens		1ft.		1ft.
Note: Proximity tests utilized a .040" diameter fiber bundle.

Features and Options:

Response time (50 microseconds)
Enhanced Dynamic Range
Interchangeable optical blocks
Clutched offset adjustment
Operational from 12 to 24 VDC…(polarity protected)
Choice with infrared, red, white, or blue LED
10-LED CONTRAST INDICATOR
Built-in connector
Waterproof housing
NPN and PNP output transistors
Short circuit protection
Light On/Dark on selector switch
Anti-pulsing protection on power up

Benefits:

Accurate and repeatable
Easy to setup
Easy to maintain
Lower maintenance costs
Lower inventory costs
Adaptable and flexible for many applications

LIGHT SOURCE SELECTION

Infrared Light Source
Invisible light – recommended in opaque object sensing applications. Infrared LED light source provides long-range sensing in either Beam Make or Beam Break modes. Infrared light maximizes the sensor’s ability to penetrate contamination found in harsh environments.

Blue Light Source
Useful for detecting translucent, transparent, plastic, or glass objects in the retroreflective mode when using the R4 optical block. Used as blue filter for color perception advantages, i.e. resolving yellow vs. white colored objects or printed registration marks.

Red (Visible) Light Source
Visible red LED light source recommended for sensing transparent/translucent objects. Outperforms infrared light in many moderate to low contrast applications. Also recommended for use with plastic fiberoptic light guides.

White Light Source
(Broadband Color Spectrum)
The “White Light” LED light source promotes easy detection of the largest variety of color marks printed on the largest variety of colored web materials. By combining a white LED light source, our Contrast Indicator, and the one-push AUTOSET setup, you have a winning combination of high performance with an easy to use sensor.

Features and Options:

Response time (50 microseconds)
Enhanced Dynamic Range
Interchangeable optical blocks
Clutched offset adjustment
Operational from 12 to 24 VDC…(polarity protected)
Choice with infrared, red, white, or blue LED
10-LED CONTRAST INDICATOR
Built-in connector
Waterproof housing
NPN and PNP output transistors
Short circuit protection
Light On/Dark on selector switch
Anti-pulsing protection on power up

Benefits:

Accurate and repeatable
Easy to setup
Easy to maintain
Lower maintenance costs
Lower inventory costs
Adaptable and flexible for many applications

Interchangeable optical blocks provide for universal applications of the SMARTEYE^® MARK III to any sensing applications from large object sensing to finite sensing of small parts, and product inspection tasks.

Type O4 Proximity	Type R4 Retroreflective	Type F4 Glass Fiberoptics	Type V4 Convergent 1" "V" Axis	Type V4A Apertured
Wide beam optics useful for short-range sensing of transparent, translucent, opaque, or irregular shaped shiny objects.	Very narrow beam optics designed to sense reflectors or reflective materials at long range. Designed for Beam Break sensing.	Adapter for use with a wide variety of glass fiberoptic light guides for both the proximity and opposed sensing modes.	Useable range of 1" to 5".	Useable range of 1".
Type O5 Proximity	Type R5 Polarized Anti-Glare Retroreflective	Type F5 Plastic Fiberoptics	Type V6 Convergent 1.5" "V" Axis	Type V8 Convergent .5" "V" Axis
Narrow beam optics useful in long-range sensing of medium to large size objects.	Polarized to reduce response to “hot spot” glare from shiny surface of detected object. Use with visible light source.	Adapter for use with a wide variety of plastic fiberoptic light guides for both the proximity and opposed sensing modes.	Useable range of 1.5" to 8".	Useable range of .25" to 5" Narrow beam optics useful for sensing small parts. Also useful for proximity sensing to minimize response to reflected light from background objects.
